Push Buttons & Egress Devices

US securitron.com 800 626 7590 customerservice.securitron@assaabloy.com Canada assaabloydss.ca 800 461 3007 sales.dss.ca@assaabloy.com

Features

Standard Features

Includes interchangeable green and red lenses Field convertible from DPST to DPDT Field selectable 12/24VDC MagnaCare lifetime replacement, no-fault, no questions asked warranty

Optional Features

Red LED on plate; for no LED select (E) Momentary or for Alternate select (A) Illumination Light Kit (LK)

Specifications

Dimensions

Stainless steel single gang plate: 4-1/2" x 2-3/4" [114mm x 70mm] Stainless steel narrow stile plate: 4-1/2" x 1-3/4" [114mm x 44mm] Black plastic surface mount: 3-7/8" x 2" [98mm x 51mm]

Electrical

29 mA at 12 VDC 40 mA at 24 VDC 3 A rated contacts

High quality Push Buttons are available in a broad selection of colors, sizes, switch types and outputs.

With a wide range of options for interchangeable lenses and field convertible outputs, push buttons can release any lock, alone or in conjunction with door closers and other hardware.

PB3 Series Push Buttons

Assorted sizes and colors with a uniform look

How to Order

MODEL SERIES ILLUMINATION SWITCH TYPE MOUNTING METHOD

PB3 E A N

PB3 Push Button (blank) Illuminated (blank) Momentary Switch (blank) Single Gang E Non-Illuminated A Alternate Switch 2 Double Gang N Narrow Gang R Remote, Surface Mount
