2021, Hanchett Entry Systems, Inc., an ASSA ABLOY Group company. Patent pending and/or patent www.assaabloydss.com/patent
600D Standard double magnetic lock 600DLB Magnetic lock with indicating LED, bond sensor and door status sensor Built-in arc suppression Instant release, no hysteresis Self-drilling TEC screws Non-aluminum parts are plated to resist corrosion E-Z mount header bracket and template provided for easy installation, no special tools required Can be used with any access control system Clear anodized (US28) inish standard Limited lifetime warranty
DURO Duranodic finish (US 40) available, specify when ordering. Dress covers in polished chrome and brass available. See "Magnetic Lock Accessories" for options.
Certifications & Listings
UL 294 listed UL 10C fire rated CAN/ULC-S104 fire door conformant ULC-S527 listed UL-864 listed
600 lbs, per magnet
Magnet size: 19-3/4" L x 1-7/8" H x 1" W Armature size: 7-1/4" L x 1-1/2" H x 5/8" W
12 or 24 VDC, field selectable Current draw, per magnet: 505, mA at 12 VDC, 260 mA at 24 VDC 600DLB bond sensor has SPDT 3A relay contacts, per magnet
+14 to +131F [-10 to +55C]
Double magnetic lock with 600 lbs of force, per door, allows control of both doors within a double door configuration. Bracket mounted and easy to install double magnetic locks can be used with any access control system and are available with LED, bond sensor and door status signalling to ensure a securely powered and sealed double door.
