320S

Features

Standard Features

Built-in arc suppression Instant release, no hysteresis Self-drilling TEC screws Non-aluminum parts are plated to resist corrosion E-Z mount header bracket and template provided for easy installation, no special tools required Can be used with any access control system Ideal for cabinets and showcases Clear anodized, (US28) inish standard Limited lifetime warranty

Options

DURO Duranodic inish (US 40) available, specify when ordering.

Specifications

Holding Force

300 lbs

Dimensions

Magnet size: 6-11/16" L x 1-1/2" H x 1-3/16" W Armature size: 5-1/2" L x 1-1/4" H x 7/16" W

Electrical

Operates on 12 or 24 VDC, field selectable Low current draw: 250 mA at 12 VDC, 130 mA at 24 VDC

Operating Temperature

+14 to +131F [-10 to +55C]

Bracket mounted, single magnetic lock with 300 lbs holding force. This versatile maglock is easy to install, operates at 12 or 24 VDC and is ideal for cabinets and showcases.

Magnetic Cabinet Lock
