ALARM CONTROLS

Features

Standard Features

Buzzer mounts Sound level 85db Continuous and slow pulse tone Buzzer mounts in 3/4 hole Bezel shaped case made of plastic

Options

Wall plates available for self-mounting: slimline (RP-23SLIMLINE) , narrow stile (TS-34NPO) , or standard single gang (RP-23)

Specifications

Dimensions

Required mounting hole: 3/4"

Electrical

Operates on 3 to 24 VDC 6 red, yellow, and black leads

Features

Standard Features

Sound level 80 to 85 dB Chime mounts in 1-1/4" hole on single gang wall plate Chime can be flange mounted

Options

Available pre-mounted on a single gang wall plate (TS-43) Single gang wall plate available for self-mounting (RP-22E)

Specifications

Dimensions

Required mounting hole: 1-1/4"

Electrical

Operates on 12 -24 VDC Current draw 95mA at 12 VDC, 140mA at 24 VDC 6 red, blue, and black leads

PA-200

Piezo Chime

PA-300

Dual Tone Piezo Buzzer

Piezo buzzer with adjustable tone can be mounted in 3/4" hole on a single gang wall plate Piezo chime can be mounted in 1-1/4" hole on a single gang wall plate
