128

Updated: April 21, 2022

US adamsrite.com 800.872.3267 customerservice.adamsrite@assaabloy.com Canada assaabloydss.ca 800.461.3007 sales.dss.ca@assaabloy.com

ELECTRIC STRIKES

All measurements are approximate and are provided for informational purposes only. Refer to the product Installation Instructions.

1-5/8" 41.3mm 1/2" 12.7mm 3-3/8" 85.7mm 8-1/4" 209.6mm 9" 228.6mm 1-5/8" 41.3mm 5/32" 4mm 1-19/32" 40.5mm INSIDE FACE OF CLOSED DOOR 8-1/4" 209.6mm 7/8" 22.2mm 7/8" 22.2mm 1-5/8" 41.3mm 4-1/2" 114.3mm PRESSURE SENSITIVE SPACER #12 X 5/8 PAN HEAD SELF TAPPING SCREW, TYPE AB 9-1/16 REMOVE STOP MATERIAL TO CLEAR FACEPLATE TURN STRIKE UPSIDE DOWN FOR OPPOSITE HAND

Jamb Preparation Installation 74R2 Dimensions

UltraLine 74R2 Electric Strikes
